Precision CNC Machined Aluminum Mounting Plates
Precision CNC machined aluminum mounting plates with accurate hole patterns, datum surfaces, slots and threaded features for industrial machinery, automation and equipment assembly.
Quick Info:
- Material: Aluminum 6061 / 6082 / 7075
- Process: CNC Milling / Drilling / Reaming / Tapping
- Tolerance: ±0.02–0.05 mm
- Surface Finish: Anodizing / Bead Blasting / As-Machined
- MOQ: 1 Piece
- Lead Time: 5–12 Working Days
Get Free Quote
Detailed Description
Precision CNC machined aluminum mounting plates provide stable reference platforms for component installation, equipment positioning and mechanical assembly. They are widely used as motor mounting plates, sensor panels, actuator bases, equipment adapters and automation mounting interfaces.
Common materials include 6061-T6, 6082 and 7075 aluminum, selected according to rigidity, weight and mechanical requirements. CNC machining enables precise hole patterns, countersinks, counterbores, threaded holes, slots and locating features to be produced in one setup.
For mounting plates used in precision assemblies, flatness, hole position and datum relationships can be controlled according to drawing requirements. Larger plates can also use optimized machining sequences to reduce deformation during material removal.
Available Surface Finishes
- As-Machined: Suitable for functional industrial mounting plates.
- Bead Blasting: Creates a uniform matte appearance.
- Clear Anodizing: Provides corrosion protection.
- Black Anodizing: Common for automation and machinery components.
- Hard Anodizing: Adds wear resistance for repeated assembly.
- Chemical Conversion Coating: Available for selected technical applications.
Structural & Functional Breakdown
- Precision Hole Patterns: Ensure repeatable component mounting.
- Threaded Holes: Provide direct fastening interfaces.
- Countersunk & Counterbored Holes: Allow flush fastener installation.
- Locating Features: Dowel holes and reference edges improve positioning.
- Machined Slots: Enable adjustment during equipment installation.
Key Features
- Controlled hole-to-hole positioning
- Custom thickness and plate dimensions
- Precision flatness and datum surfaces
- Multiple threaded and locating features
- Aluminum grades for different strength requirements
- Prototype through batch production
Applications
- Automation Systems
- Motor Mounting Plates
- Robotics
- Sensor Platforms
- Industrial Machinery
- Optical Equipment
- Assembly Equipment
- Testing Systems
